ion chromatograph
CIC-D180 Ion Chromatograph

CIC-D180 is a new generation of intelligent ion chromatograph of SHINE. The simple pipeline layout and various component configurations make CIC-D180 flexible and changeable. It can be equipped with various detectors on demand to realize the combination technology easily. It can also be transformed into dual system and two-dimensional ion chromatograph, which is suitable for various application scenarios.

Technology Advantage

High definition touch screen can display the flow path and running status of the instrument in real time, operate with one key and view at any time;

The built-in eluent generator generates high-purity KOH and MSA eluent by electrolysis, which saves manual configuration time and completes more detection items by gradient elution;

Built in gas-liquid separation system can filter out the bubbles in the flow path, enhance the stability;

In the heating degassing unit, there is an integrated on-line vacuum chamber, which can remove the gas in the eluent on-line to make the experimental results more accurate.

The intelligent alarm function can recognize the leaks.

Using intelligent detector to detect the residual liquid in the eluent cartridge in real time.

Clarity software can realize the detection and control of each component of the platform, and output the analysis results.

Mobile APP can master every step of analysis in real time without manual attendance, making the work easy and efficient.



Make an inquiry Ask for Remote DEMO

Pump

Maximum Pressure:35 MPa(PEEK)

Pressure Display Accuracy:≤0.1MPa

Flow Rate Range:0.001~9.999mL/min



Conductivity Detector

Cell Volume:≤0.8μL

Detection Range: 0~50000μS/cm

Detection Resolution: ≤0.0020nS/cm

Electronic Noise:0.02nS

Maximum Pressure:10.0MPa



Built-in Eluent Generator

Eluent Types : KOH/MSA

Eluent Concentration Range :0.1-100mM

Gradient Accuracy :0.2%

Flow Rate Range:0.1-5.0mL/min

 Pressure:≤30MPa



Power Requirements:150W

Dimensions(L*W*H*):500*360*550 (mm)

Net Weight(KGS):32

Gross Weight(KGS):40




Installation of CIC-D180 Ion Chromatograph

CIC-D180 ion chromatograph

Top 10 events of SHINE oversea market in 2020

SH-AP-2 Anion Column

4.0*250mm
SH-AP-2 Anion Column

SH-AP-3 Anion Column

4.0*150mm
SH-AP-3 Anion Column

Self-regenerating suppressor

SHY-A-6/SHY-C-5
Self-regenerating Electrolytic Micro-membrane Suppressor

Cation Eluent Generator

SHRF-10
Cation Eluent Generator

Chromatography Software

Clarity
Chromatography Software

Eluent Generator Cartridge

EGC-KOH/EGC-MSA
Eluent Generator Cartridge

Ion ChromatographBrochure

Version: 10/09/2021
